Mounting Stone

Low-Expansion, Fast-Setting Stone

ISO Type 3

A very hard, fast setting gypsum material formulated expressly for mounting casts to articulators. Its very low setting expansion prevents inaccuracies in occlusal cast relationships that result when conventional model stone or plaster is used. Although MOUNTING STONE has excellent stacking qualities, it moves very freely under the slightest pressure during its working time. It can be used as a model stone when a rapid set is required.

Physical Properties

Water/Powder Ratio
26 mL/100 g
Working Time
2 - 3 minutes
Setting Time
5 minutes
Setting Expansion
Compressive Strength, Wet (1hr.)
4,600 psi (32 MPa)
Compressive Strength, Dry (48 hrs.)
8,500 psi (59 MPa)
Item No. Description
18730 100 - 100g Package
02917 11 kg (25 lb.) Carton
33197 22 kg (50 lb.) Carton
18731 100 - 100g Package
18740 11 kg (25 lb.) Carton
33200 22 kg (50 lb.) Carton
Trial Pack
01236 4-100g packs of Mounting Stone Buy
